Aquaspira for Housing

Approved for use in all water company regions. Aquaspira is the preferred choice for large diameter pipe applications across the UK.

4%

The weight of
concrete pipes

60%

Less loads &
offloading time

75%

Fewer plant
movements across site

Maximise Land Utilisation

Utilising the space beneath the roads for stormwater storage is not only efficient, it can also free up valuable land for properties. Our integrated pipes and access system lifts efficiency and simplicity to new levels.

Most Popular Applications

The preferred choice for large diameter pipe applications across the UK

We’ve got you covered.

How it works for you

Reduced Program

  • Better by design: maximum online storage = minimum offline tanks
  • Quick & efficient installation using light weight, sealed, push-fit pipes and access units
  • Access units save days of construction time for each manhole

Minimal Footprint

  • Smallest pipe OD and trench width available
  • Access units fit within the same narrow trench

Maximum Capacity

  • Pipes and access units up to 2250mmØ easily fit within the road
  • Up to 4m³ storage per metre

Safe Environment for Homeowners

  • No above ground water hazards
  • Simple online systems = reduced risk of blockage and maintenance
  • Maintenance easily undertaken in the public highway, not in POS areas
  • Eliminates risk of odours from stagnant water in ponds & swales

Ideal for Brownfield

  • Fully sealed pipe & access system
  • No ingression of contaminated groundwater
  • Reduced excavation of potentially contaminated ground
  • Excellent chemical resistance

Carbon Reduction

  • 25% less excavation*
  • 60% fewer deliveries*
  • Optimum utilisation of land, minimising greenfield land-take

*compared to equivalent size concrete pipe

Long-Term Performance

  • BS EN 752 Compliant: ‘Inspect, Maintain, Clean and Remove Debris’
  • Single flow-path for optimal self-cleansing
  • 120 year design life

National, Regional, and Local Housebuilders are experiencing the benefits

Storage Comparison

This simple comparison shows how you can increase online capacity by over 30% within the same footprint and less excavation.

Storage Capacity Required = 300m³Pipe Type
Linear MetreConcreteAquaspira
Nominal Diameter12001500
Outside Socket Diameter15901590
Trench Width (approx)Equal
Trench Depth (approx)300mm more300mm less
Capacity per linear meter of pipe (m³)1.131.77
Metres required to achieve storage capacity265169

Storage Comparison

This simple comparison shows how you can increase online capacity by over 30% within the same footprint and less excavation.

Storage Capacity Required = 600m³Pipe Type
ConcreteAquaspira
Nominal Diameter15001800
Outside Socket Diameter20101915
Trench Width (approx)95mm more95mm less
Trench Depth (approx)400mm more 95mm less
Capacity per linear meter of pipe (m³)1.772.54
Metres required to achieve storage capacity338236
